Fine sand recovery system

【Capacity】:15-300t/h
【Feed Size】:«10mm
【Power】:5.5-15kW
【Application】: 1. Sand and Gravel Pits: For producing high-quality concrete sand and mortar sand.
2. Crushed Stone Plants: To clean and dewater crusher dust (manufactured sand) to make it a valuable product.
3. Construction and Demolition (C&D) Waste Recycling: For washing and upgrading recycled concrete aggregate (RCA).
4. Industrial Sands: Processing silica sand, frac sand, and other specialized sands where low clay and moisture content are critical.

If you want to buy the product, contact us immediately, product prices will have a greater discount!

Email: info@zzhochang.com

Chat Online Get Latest Price

Enter email to free download PDF

Name:

* Email:

Filling your email or name in the form for downloading the PDF can help you find the information you are looking for!

Overview

Why choose us ?
Our Value Message is “QUALITY IS OUR CULTURE .”
“WITH US YOUR MONEY IN SAFE AND YOUR BUSINESS IN SAFE!”
1 .Competitive advantage Products
2.Confidentially Agreement“ Business Secret CONTRACT”
3.Quality Assurance CONTRACT
4.SMALL Order welcomed
5.After sales services 24x7

What Is Sand Washing And Dewatering Machine?
A sand washing and dewatering machine is a specialized piece of equipment designed to remove impurities (mud, clay, dust, and light minerals) from raw sand while simultaneously reducing its moisture content. Unlike standalone sand washers (which produce wet sand requiring additional drying) or dewatering screens (which can’t remove fine impurities). This integrated system not only cleans sand effectively but also reduces moisture content to optimal levels, making it ready for immediate use or transport.

Sand washing and dewatering machine Features:

High quality;Superior Cleaning& Quality. Effectively removes clay, silt, and impurities to produce high-purity sand that meets construction standards.
Customized Design; Excellent dewatering performance. Reduces moisture content to 8-15%, making sand ready for immediate use or transport.
Good performance; Water& cost efficiency. Features closed-loop water recycling systems that minimize water consumtion and operational costs.

Fine sand recovery system Working principle:
After the pre-processed material enters the storage tank, the washing wheel starts to rotate through the motor and reducer, and the material is picked up from the water and passed through the mesh in the washing wheel. The water and the material below the mesh size are missing. During the rotation of the washing wheel, the material is in full contact with the water, and water is used to remove the impurities on the surface of the material. so the material is cleaner. Then the material enters the dewatering device and removes a lot of moisture through the vibrating screen, which makes the material more convenient to store and transport.

Fine sand recovery system Specification:

Model	Hydrocyclone (mm)	Dewatering screen size (mm)	Bucket sand washer	Feed size (mm)	Capacity (t/h)	Power (kW)
HC26-25	250	900*1800	XS2610	0-10	15-20	22
HC26-35	350	900*1800	XS2610	0-10	20-25	22.7
HC26-50	250*2	1200*2400	XS2610	0-10	30-50	37
HC26-70	350*2	1200*2400	XS2610	0-10	40-60	37.7
HC28-70	350*2	1500*3000	XS2816	0-10	50-80	45.4
HC30-70	350*2	1800*4200	XS3016	0-10	80-100	48.4

Superior Cleaning & Quality. Effectively removes clay, silt, and impurities to produce high-purity sand that meets construction standards.

Equipments Included in the Production Line
