Jaw crusher

【Capacity】:1.2-510 t/h

【Feed Size】:125-1020 mm

【Adjusting range of outlet】:15-300 mm

【Application】:all kinds of stone with highest anti-pressure strength 320MPa. It is ideally suitable for primary and secondary stone crushing in mine, metallurgic industry, chemical industry, building material .Such as Processed Materials: Concrete waste, iron ore, copper ore, gold ore, manganese ore, gravel, granite, river stone, basalt, limestone, dolomite, quartz, coal, etc.

If you want to buy the product, contact us immediately, product prices will have a greater discount!

Email: info@zzhochang.com

Chat Online Get Latest Price

Enter email to free download PDF

Name:

* Email:

Filling your email or name in the form for downloading the PDF can help you find the information you are looking for!

Overview

Jaw crusher

I Overview
1.Brief Introduction
A jaw crusher is a machine designed to break large rocks into smaller rocks, gravel, or sand by compressive force caused by two jaw plates.

2.Structure info.(Including Base Materials)
Jaw crusher is mainly combined by frame, movable jaw, eccentric shaft, pulley, flywheel, adjustment seat, tension rods, toggle plates, jaw plates and side guard plates.

NO.	Parts	Material
1	Frame	Q235
3	Movable jaw	ZG45 or ZG45
5	Eccentric shaft	42MnMoV, 30MnMoB or 34MnMo
6	Jaw plate	ZGMn13 or ZGMn13Cr2
7	Side guard plate	ZGMn13 or ZGMn13Cr2
8	Toggle plate	HT150 or HT200
10	Tension rod	45

3.Why choose us?

II Detailed information
1.Products Details
Jaw crusher is widely applied for primary crushing of hard rocks, ores, so it is widely used in the following industries : mineral processing , quarry, construction materials, water conservancy and hydro power etc.

2.Features:

1. Large crushing ratio and even product size;
2. Large and reliable adjusting range of discharge port;
3. Safe and reliable lubrication system, easy maintenance and spare parts replacement;
4. Simple structure and low operation cost;
5. Low noise and little dust.

3. Technical parameter of jaw crusher

Model	Feed opening (mm)	Max.feeding size (mm)	Adjusting range of discharge opening (mm)	Processing capacity (t/h)	Rotation speed of eccentric shaft (r/min)	Motor power (kw)	Total weight (t)	Dimensions (L×W×H) (mm)
PE-150×250	150×250	125	10-40	1-3	250	4P 5.5	0.8	720×660×850
PE-200×300	200×300	180	15-50	2-6	260	4P 7.5	1.2	910×750×990
PE-200×350	200×350	180	18-70	3-10	260	4P 11	1.5	1000×870×990
PE-250×400	250×400	210	20-60	5-20	300	6P 15	2.8	1300×1090×1270
PE-400×600	400×600	340	40-100	16-60	275	6P 30	7	1730×1730×1630
PE-500×750	500×750	425	50-100	40-110	275	6P 55	12	1980×2080×1870
PE-600×750	600×750	500	150-200	80-240	275	6P 55	15.8	2070×2000×1920
PE-600×900	600×900	500	65-160	50-180	250	6P 55	17	2190×2206×2300
PE-750×1060	750×1060	630	80-140	110-320	250	8P 110	29	2660×2430×2800
PE-800×1060	800×1060	640	130-190	130-330	250	8P 110	29.8	2710×2430×2800
PE-830×1060	830×1060	650	160-220	150-336	250	8P 110	30.7	2740×2430×2800
PE-870×1060	870×1060	660	200-260	190-336	250	8P 110	31.5	2810×2430×2800
PE-900×1060	900×1060	685	230-290	230-390	250	8P 110	33	2870×2420×2940
PE-900×1200	900×1200	750	95-165	220-450	200	8P 110	52	3380×2870×3330
PE-1000×1200	1000×1200	850	195-265	315-500	200	8P 110	55	3480×2876×3330
PE-1200×1500	1200×1500	1020	150-350	400-800	180	6P 160-220	100.9	4200×3300×3500
PE-1500×1800	1500×1800	1200	220-350	500-1000	180	8P 280-355	139	5160×3660×4248
PE-1600×2100	1600×2100	1500	300-400	1300-2200	160	8P 350-380	150.6	6210×4013×4716
PEX-150×750	150×750	120	18-48	8-25	320	4P 15	3.8	1200×1530×1060
PEX-250×750	250×750	210	25-60	13-35	330	6P 22	5.5	1380×1750×1540
PEX-250×1000	250×1000	210	25-60	16-52	330	6P 30	7	1560×1950×1390
PEX-250×1200	250×1200	210	25-60	20-61	330	6P 37	9.7	2140×1660×1500
PEX-300×1300	300×1300	250	20-90	16-105	300	6P 55	15.6	2720×1950×1600
